FED COMP 32/64 BIT PCIE ADAPTER product photo
Allied Telesis

FED COMP 32/64 BIT PCIE ADAPTER

Allied Telesis AT-2911SX/SC-901, Internal, Wired, PCI Express, Fiber, 1000 Mbit/s

MSRP

$689.94

Quantity

Get a real, competitive price from a Dataworld account manager, usually the same day.

View your quote request

Product identifiers

SKU
AT-2911SX/SC-901
UPC
0767035196619
Category
Network Devices

Overview

The Allied Telesis FED COMP 32/64 BIT PCIE ADAPTER is a network interface card that integrates into systems via PCIe architecture. As a networking component, it is engineered to support data communication across enterprise and institutional environments where compatible host systems are deployed. Allied Telesis network interface products are designed to work with standard PCIe-enabled platforms and infrastructure. Dataworld is an authorized Canadian reseller of Allied Telesis products, serving Canadian businesses across the country with genuine equipment sourced through authorized distribution channels. We provide quotations in Canadian dollars and deliver real pricing to qualified customers upon request. Whether you require a single unit or multiple deployments, we work with you to source this product efficiently and professionally.

Specifications

Ports & interfaces

Connectivity technology
Wired
Host interface
PCI Express
Interface
Fiber
Fiber ports quantity
1
Fiber optic connector
SC

Network

Maximum data transfer rate
1000 Mbit/s
Networking standards
IEEE 802.1p, IEEE 802.1Q, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Fiber ethernet cabling technology
1000BASE‑ZX
Jumbo frames support
Yes
Quality of Service (QoS) support
Yes

Design

Internal
Yes
LED indicators
Yes
Certification
UL FCC/EN55022 A TUV EN55024 CE C-TICK VCCI

Power

Output voltage
3.3 V
Power consumption (typical)
9.2 W

System requirements

Windows operating systems supported
Yes
Linux operating systems supported
Yes

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-25 - 70 °C
Operating relative humidity (H-H)
5 - 90%

Weight & dimensions

Width
87 mm
Height
56 mm
Weight
700 g

Technical details

Compliance certificates
RoHS

Logistics data

Harmonized System (HS) code
85176990

Other features

Flow control support
Yes
Management protocols
SNMP
Link/Act LED
Yes
